Kingflex
1 / 1
| Technical Data | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m³ | 45-65Kg/m³ | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10 ⁻¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ | - | ≥10000 | - |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406, ISO4589 |
| Water Absorption, % by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | - | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | Good | GB/T 7762-1987 | |
| Resistance to U.V. and weather | Good | ASTM G23 | |
Rubber foam insulation is approved by BS476. You can choose Class 0 or Class 1 according to requirements. It is self-extinguishing and produces no drips according to ASTM D635-91.
Rubber foam is your smart choice for energy saving, with low thermal conductivity ≤0.034 W/m.K.
No dust and fiber, CFC free, Low VOCs, No fungal growth, Negligible bacterial growth.
Due to rubber foam's high flexible performance, it is easy to bend around irregular pipes, cut into different shapes and sizes, saving both labor and materials.
We can custom various colors such as red, blue, green, grey, yellow, and so on. Your finished piping lines will be much nicer and it makes it easy to distinguish different pipes for maintenance.
The rubber foam insulation is approved by BS476 and is available in Class 0 or Class 1 ratings. According to ASTM D635-91, it is self-extinguishing and produces no drips under fire conditions.
The material provides excellent thermal insulation, with a low thermal conductivity of ≤0.034 W/m.K under general conditions, and as low as ≤0.030 W/(m.k) at -20°C.
Yes, it is eco-friendly. It is CFC-free, produces no dust or fiber, releases low VOCs, and exhibits no fungal or negligible bacterial growth.
This insulation material maintains stable properties across a wide temperature range, from -50°C to 110°C, tested in compliance with GB/T 17794-1999.
Yes, we can custom-produce various colors including red, blue, green, grey, and yellow. This color coding helps aesthetic layout and makes pipeline maintenance easier.
Absolutely. Due to its high flexibility, it can easily bend around complex pipe geometries and can be cut cleanly into custom shapes, saving time and installation costs.
