Available in several thicknesses and self-adhesive.
Meet the many needs in the fields of both civil and industrial plants for refrigeration, air conditioning, heating and plumbing, the insulation of tanks, pipe fittings, water ducts etc.
The sheets are designed for the insulation on very large surfaces.
Ideal for insulation of metal sheet pipes and plenumboxes.
Material: Synthetical rubber with closed cell structure.
Insulation Sheet Dimensions
Thickness
Width 1m
Width 1.2m
Width 1.5m
Inches
mm
Size(L*W)
㎡/Roll
Size(L*W)
㎡/Roll
Size(L*W)
㎡/Roll
1/4"
6
30 × 1
30
30 × 1.2
36
30 × 1.5
45
3/8"
10
20 × 1
20
20 × 1.2
24
20 × 1.5
30
1/2"
13
15 × 1
15
15 × 1.2
18
15 × 1.5
22.5
3/4"
19
10 × 1
10
10 × 1.2
12
10 × 1.5
15
1"
25
8 × 1
8
8 × 1.2
9.6
8 × 1.5
12
1 1/4"
32
6 × 1
6
6 × 1.2
7.2
6 × 1.5
9
1 1/2"
40
5 × 1
5
5 × 1.2
6
5 × 1.5
7.5
2"
50
4 × 1
4
4 × 1.2
4.8
4 × 1.5
6
Technical Data
Property
Unit
Value
Test Method
Temperature range
°C
(-50 - 110)
GB/T 17794-1999
Density range
Kg/m³
45-65Kg/m³
ASTM D1667
Water vapor permeability
Kg/(m.s.pa)
≤0.91×10⁻¹³
DIN 52 615 / BS 4370 Part 2 1973
μ
-
≥10000
-
Thermal Conductivity
W/(m.k)
≤0.030 (-20°C)
ASTM C 518
≤0.032 (0°C)
≤0.036 (40°C)
Fire Rating
-
Class 0 & Class 1
BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index
-
25/50
ASTM E 84
Oxygen Index
-
≥36
GB/T 2406, ISO 4589
Water Absorption, % by Volume
%
20%
ASTM C 209
Dimension Stability
-
≤5
ASTM C534
Fungi resistance
-
Good
ASTM G21
Ozone resistance
Good
GB/T 7762-1987
Resistance to U.V. and weather
Good
ASTM G23
Central air-conditioning system pipelines and equipment, living hot water pipes and equipment, industrial low-temperature piping and equipment, as well as refrigeration system, in particular, apply in electronics, food clean, chemical plant and important public buildings where need higher requirement of cleanness, sound insulation and fire performance demanding.
Frequently Asked Questions (FAQ)
Q: What is the base material of these insulation sheets?
The sheets are made of premium synthetical rubber with a closed-cell structure, ensuring excellent thermal insulation and moisture resistance.
Q: What is the operational temperature range?
These insulation sheets are designed to perform reliably within a wide temperature range of -50°C to 110°C, suitable for both low-temperature refrigeration and heating systems.
Q: Are these sheets fire-resistant?
Yes, the insulation material has a Fire Rating of Class 0 & Class 1 (tested to BS 476 Part 6 & 7) and an Oxygen Index of ≥36.
Q: Can they be used on large surfaces and complex pipe fittings?
Absolutely. The sheets are specifically designed for insulating very large surfaces, metal sheet pipes, plenum boxes, and complex pipe fittings, and they are available in a self-adhesive format for easy installation.
Q: How do they perform against environmental factors like U.V. and ozone?
They offer outstanding durability with rated "Good" resistance to fungi (ASTM G21), ozone (GB/T 7762-1987), and U.V./weathering (ASTM G23).
