This self adhesive foam insulation roll is an environmental protection insulation material featuring a closed cell structure with a self-adhesive backing. It is manufactured without the use of CFC'S, HFC'S OR HCFC'S. It is also formaldehyde-free, low-VOCs, fiber-free, dust-free, and highly resistant to mold and mildew.
Features exceptionally low thermal conductivity to minimize energy transfer.
Designed to effectively reduce noise levels and prevent sound transmission.
Provides robust resistance against water absorption and complies with safety standards.
Offers excellent strength properties to resist compression and deformation.
Ensures persistent performance against moisture vapor transmission.
Designed with self-adhesive backing to allow swift and secure installation.
| Dimensions Guide | |||||||
|---|---|---|---|---|---|---|---|
| Thickness | Width 1m | Width 1.2m | Width 1.5m | ||||
| Inches | mm | Size(L*W) | ㎡/Roll | Size(L*W) | ㎡/Roll | Size(L*W) | ㎡/Roll |
| 1/4" | 6 | 30 × 1 | 30 | 30 × 1.2 | 36 | 30 × 1.5 | 45 |
| 3/8" | 10 | 20 × 1 | 20 | 20 × 1.2 | 24 | 20 × 1.5 | 30 |
| 1/2" | 13 | 15 × 1 | 15 | 15 × 1.2 | 18 | 15 × 1.5 | 22.5 |
| 3/4" | 19 | 10 × 1 | 10 | 10 × 1.2 | 12 | 10 × 1.5 | 15 |
| 1" | 25 | 8 × 1 | 8 | 8 × 1.2 | 9.6 | 8 × 1.5 | 12 |
| 1 1/4" | 32 | 6 × 1 | 6 | 6 × 1.2 | 7.2 | 6 × 1.5 | 9 |
| 1 1/2" | 40 | 5 × 1 | 5 | 5 × 1.2 | 6 | 5 × 1.5 | 7.5 |
| 2" | 50 | 4 × 1 | 4 | 4 × 1.2 | 4.8 | 4 × 1.5 | 6 |
| Technical Specifications | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m³ | 45-65Kg/m³ | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10 ﹣¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ | - | ≥10000 | - |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406, ISO4589 |
| Water Absorption, % by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | - | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | Good | GB/T 7762-1987 | |
| Resistance to U.V. and weather | Good | ASTM G23 | |
What are the primary certifications for this self-adhesive foam insulation roll?
This insulation roll holds multiple global certifications including BS476, UL94, DIN5510, ASTM, CE, REACH, ROHS, and GB, ensuring it meets strict safety and environmental standards.
What temperature range can this foam insulation withstand?
The material is highly stable and performant across an operating temperature range from -50°C to 110°C, making it suitable for both cold and hot systems.
Does this product contain harmful ozone-depleting materials?
No, the foam insulation roll is completely manufactured without the use of CFC'S, HFC'S, or HCFC'S. It is also formaldehyde-free, low VOC, fiber-free, and dust-free.
How does this insulation roll perform against fire hazards?
It features excellent fire safety characteristics, achieving a Class 0 & Class 1 rating according to BS 476 Part 6 & 7 testing standards, and a 25/50 rating in ASTM E 84 tests.
What benefits does a closed cell structure provide?
A closed cell structure prevents the penetration of moisture and water vapor, ensures low thermal conductivity over time, and provides strong resistant properties against mold and structural deformation.
