This kind of insulation tube / pipe is made by NBR/PVC with excellent performance as its main raw material. Served with varied subsidiary materials of high quality, the tube foam is made by special craft foam and feels very soft. We can supply rubber foam products according to clients' specific requirements in terms of shapes, colors, hardness levels and other features.
| Technical Data | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m³ | 45-65Kg/m³ | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10 ﹣¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ | - | ≥10000 | |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | 25/50 | ASTM E 84 | |
| Oxygen Index | ≥36 | GB/T 2406,ISO4589 | |
| Water Absorption, % by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | ≤5 | ASTM C534 | |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | Good | GB/T 7762-1987 | |
| Resistance to U.V. and weather | Good | ASTM G23 | |
The high density and closed structure of selected raw material has the ability of low thermal conductivity and stable temperature and has an isolation effect of hot and cold medium.
When burned by fire, the insulation material do not melt and resulting in low smoke and do not make the flame spread which can guarantee the using safety; the material is determined as nonflammable material and the range of Using temperature is from -50℃ to 110℃.
The environmental friendly raw material has no stimulation and pollution, no hazard to health and environment. Moreover, it can avoid the mold growth and mouse biting; The material has the effection of corrosion-resistant, acid and alkali, it can increase the life of using.
It is convenient to install due to it is not need to install other auxiliary layer and it is just cutting and conglutinating. It will save the manual work greatly.
These insulation tubes are made primarily of NBR/PVC with high-quality subsidiary materials, resulting in a soft and flexible texture with excellent physical performance.
The recommended service temperature range for this insulation material is from -50℃ to 110℃, making it suitable for hot and cold media.
Yes, the material features a Class 0 and Class 1 fire rating in accordance with BS 476 Part 6 and 7. It is flame retardant, does not melt, and produces low smoke, preventing the spread of flames.
Yes. It is made from environmentally friendly raw materials with zero pollution and has good resistance against fungi, ozone, UV, acids, and alkalis, extending its service life.
They are exceptionally easy to install. The product requires no extra auxiliary layer and can be easily cut and conglutinated, saving significant labor time.
