China NBR PVC RUBBER FOAM SHEET Manufacturer, Pricelist

1 / 1

China NBR PVC RUBBER FOAM SHEET Manufacturer, Pricelist

Rubber plastic foaming thermal insulation materials are produced by the cutting-edge technology introduced from abroad and the automatic production line, with nitrile-Butadiene rubber (NBR)and polyvinyl chloride(PVC) in excellent performances as the main materials and via special processes of ban burying, sulfuration, foaming, etc.

Send Inquiry

Product Description

⚡

1. Low and Stable Thermal Conductivity: 0.034w/m.k

💧

2. Low Water Absorption Rate

🔥

3. Good Fireproof and Soundproof Performance

💪

4. Good Flexibility and Tenacity

⏳

5. Good Aging Resistance Performance

🛡️

6. Good Vibration Resistance

Rubber Foam Sheet Dimensions
Thickness		Width 1m		Width 1.2m		Width 1.5m
Inches	mm	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll
1/4"	6	30 × 1	30	30 × 1.2	36	30 × 1.5	45
3/8"	10	20 × 1	20	20 × 1.2	24	20 × 1.5	30
1/2"	13	15 × 1	15	15 × 1.2	18	15 × 1.5	22.5
3/4"	19	10 × 1	10	10 × 1.2	12	10 × 1.5	15
1"	25	8 × 1	8	8 × 1.2	9.6	8 × 1.5	12
1 1/4"	32	6 × 1	6	6 × 1.2	7.2	6 × 1.5	9
1 1/2"	40	5 × 1	5	5 × 1.2	6	5 × 1.5	7.5
2"	50	4 × 1	4	4 × 1.2	4.8	4 × 1.5	6

Rubber Foam Sheet are widely used in sound isolation of wall planking, sound absorption in air ducts, and sound absorbing decorations in entertainment spaces. It can also be used for shock resistance and pressure relief in instruments and equipment.

Technical Data
Property	Unit	Value	Test Method
Temperature range	°C	(-50 - 110)	GB/T 17794-1999
Density range	Kg/m3	45-65Kg/m3	ASTM D1667
Water vapor permeability	Kg/(m.s.pa)	≤0.91×10 ﹣¹³	DIN 52 615 / BS 4370 Part 2 1973
μ	-	≥10000	-
Thermal Conductivity	W/(m.k)	≤0.030 (-20°C)	ASTM C 518
		≤0.032 (0°C)
		≤0.036 (40°C)
Fire Rating	-	Class 0 & Class 1	BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index	-	25/50	ASTM E 84
Oxygen Index	-	≥36	GB/T 2406, ISO4589
Water Absorption, % by Volume	%	20%	ASTM C 209
Dimension Stability	-	≤5	ASTM C534
Fungi resistance	-	Good	ASTM 21
Ozone resistance		Good	GB/T 7762-1987
Resistance to U.V. and weather		Good	ASTM G23

Frequently Asked Questions

What are the main advantages of using these Rubber Foam Sheets?

These sheets offer a low and stable thermal conductivity of 0.034w/m.k, exceptionally low water absorption rates, and outstanding fireproof and soundproof features. Additionally, they exhibit excellent flexibility, robust aging resistance, and strong vibration resistance.

What applications are Rubber Foam Sheets best suited for?

They are widely applied in sound isolation for wall planking, sound absorption inside air ducts, acoustic treatment in entertainment spaces, as well as providing shock absorption and pressure relief in sensitive equipment and instruments.

What is the thermal conductivity rating of the sheet under different temperatures?

According to standard ASTM C 518 tests, the thermal conductivity values are: ≤0.030 W/(m.k) at -20°C, ≤0.032 W/(m.k) at 0°C, and ≤0.036 W/(m.k) at 40°C.

What fire ratings do these foam sheets comply with?

The rubber foam sheet meets Class 0 and Class 1 fire rating standards in accordance with BS 476 Part 6 & Part 7, boasting an oxygen index of ≥36 and a Flame Spread & Smoke Developed Index of 25/50 under ASTM E 84.

Do they perform well under outdoor conditions, UV, and moisture?

Yes, they show excellent resistance to UV, weathering (ASTM G23), and ozone (GB/T 7762-1987). With a low water vapor permeability (≤0.91×10 ﹣¹³ Kg/(m.s.pa)) and high water resistance, they are highly reliable in high-humidity or outdoor environments.
