Wholesale Kingflex Closed Cell Elastomeric NBR Foam Rolls Factories, Pricelist

Kingflex closed cell nitrile rubber foam sheet roll for Refrigerating System.

Send Inquiry

Product Description

Rubber foam insulation material is soft heat-insulating, heat-preservation and energy conservation materials made with advanced technology and advanced full-automatic continuous production line imported from abroad, using polyvinyl chloride (NBR, PVC) as main raw materials and other high quality auxiliary materials through foaming and so on special procedure.

Rubber Foam Dimensions
Thickness		Width 1m		Width 1.2m		Width 1.5m
Inches	mm	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll	Size(L*W)	㎡/Roll
1/4"	6	30 × 1	30	30 × 1.2	36	30 × 1.5	45
3/8"	10	20 × 1	20	20 × 1.2	24	20 × 1.5	30
1/2"	13	15 × 1	15	15 × 1.2	18	15 × 1.5	22.5
3/4"	19	10 × 1	10	10 × 1.2	12	10 × 1.5	15
1"	25	8 × 1	8	8 × 1.2	9.6	8 × 1.5	12
1 1/4"	32	6 × 1	6	6 × 1.2	7.2	6 × 1.5	9
1 1/2"	40	5 × 1	5	5 × 1.2	6	5 × 1.5	7.5
2"	50	4 × 1	4	4 × 1.2	4.8	4 × 1.5	6

✓

High Safety: The product is inflammable and has high safety performance.

✓

High Flexibility: Flexible material, suitable for various shapes and easy installation.

✓

Vapor Barrier: The closed cell structure prevents the penetration of water vapor and prolongs the service life.

Rubber Foam Technical Data
Property	Unit	Value	Test Method
Temperature range	°C	(-50 - 110)	GB/T 17794-1999
Density range	Kg/m³	45-65Kg/m³	ASTM D1667
Water vapor permeability	Kg/(m.s.pa)	≤0.91×10 ﹣¹³	DIN 52 615 BS 4370 Part 2 1973
μ	-	≥10000	-
Thermal Conductivity	W/(m.k)	≤0.030 (-20°C)	ASTM C 518
		≤0.032 (0°C)
		≤0.036 (40°C)
Fire Rating	-	Class 0 & Class 1	BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index	-	25/50	ASTM E 84
Oxygen Index	-	≥36	GB/T 2406, ISO4589
Water Absorption, % by Volume	%	20%	ASTM C 209
Dimension Stability	-	≤5	ASTM C534
Fungi resistance	-	Good	ASTM 21
Ozone resistance		Good	GB/T 7762-1987
Resistance to U.V. and weather		Good	ASTM G23

Frequently Asked Questions

Q1: What are the main raw materials used in this rubber foam insulation?

A1: This material is manufactured using high-quality polyvinyl chloride (NBR, PVC) as the primary raw materials, blended with auxiliary materials through a specialized foaming process on an automated continuous production line.

Q2: What is the applicable temperature range for this insulation material?

A2: The insulation is designed to operate effectively within a temperature range of -50°C to 110°C, tested in compliance with standard GB/T 17794-1999.

Q3: How does the closed-cell structure benefit the performance of the insulation?

A3: The closed-cell structure acts as a reliable barrier against water vapor penetration. This prevents moisture accumulation inside the material, ensuring stable thermal performance and extending the overall service life.

Q4: What is the fire rating and safety performance of this rubber foam?

A4: The product achieves a Class 0 and Class 1 fire rating according to BS 476 Part 6 & 7. It has a Flame Spread and Smoke Developed Index of 25/50 (ASTM E 84) and an Oxygen Index of ≥36 (GB/T 2406, ISO4589), ensuring high safety performance.

Q5: Is this rubber foam resistant to mold, UV, and outdoor weather conditions?

A5: Yes, the material offers good resistance to fungi (ASTM 21), ozone (GB/T 7762-1987), and UV/weathering (ASTM G23), making it highly durable under tough environmental conditions.

Q6: Is it easy to install this material on complex pipeline shapes?

A6: Yes, the material is highly flexible, making it ideal for covering curves, bends, and irregular structures easily. This flexibility ensures a seamless fit and simple installation.
