Wholesale The rubber foam insulation tube products Factories, Pricelist

We produce Rubber-plsatic Foamed Heat Preservation Products(PVC/NBR)by introducing newest technology and craft and automatic processing line.The major materials we use are NBR/PVC,which are undergone ban bury,vulcanization and foam,Therefore,the main characteristics are:Low density,close bubble structure,low thermal conductivity,Water vapor Transmissibility extremely low,low water -absorptive ability,Fire-proof performance well,superior anti-agde performance,good flexibility,easy to install.This product is suitable for a wide temperature range,from -50℃ is to 110℃ ,also has good anti-adge performance and durability. Normal wall thicknesses of 1/4”, 3/8″, 1/2″, 3/4″,1″, 1-1/4”, 1-1/2″ and 2” (6, 9, 13, 19, 25 , 32, 40 and 50mm). Standard Length with 6ft (1.83m) or 6.2ft(2m).

Send Inquiry

Product Description

Key Benefits & Features

✓

Excellent fire-resistance performance & Sound absorption.

✓

Low thermal conductivity (K-Value).

✓

Good moisture resistance.

✓

No crust rough skin.

✓

Good pliability and good anti-vibration.

✓

Environmentally friendly.

✓

Easy to install & Nice appearance.

✓

High oxygen index and low smoke density.

The rubber foam insulation tube products are produced by imported high-end technology and automatic continuous equipment. We have developed a rubber foam insulation material with excellent performance through in-depth research. The major materials we use are NBR/PVC.

Technical Data
Property	Unit	Value	Test Method
Temperature range	°C	(-50 - 110)	GB/T 17794-1999
Density range	Kg/m³	45-65Kg/m³	ASTM D1667
Water vapor permeability	Kg/(m.s.pa)	≤0.91×10 ﹣¹³	DIN 52 615 / BS 4370 Part 2 1973
μ	-	≥10000	-
Thermal Conductivity	W/(m.k)	≤0.030 (-20°C)	ASTM C 518
		≤0.032 (0°C)
		≤0.036 (40°C)
Fire Rating	-	Class 0 & Class 1	BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index	-	25/50	ASTM E 84
Oxygen Index	-	≥36	GB/T 2406,ISO4589
Water Absorption, % by Volume	%	20%	ASTM C 209
Dimension Stability	-	≤5	ASTM C534
Fungi resistance	-	Good	ASTM 21
Ozone resistance		Good	GB/T 7762-1987
Resistance to U.V. and weather		Good	ASTM G23

Frequently Asked Questions (FAQ)

Q1: What are the main materials used in these insulation tubes?

A1: The primary materials used are high-quality NBR/PVC, which are manufactured using imported high-end technology and automatic continuous equipment to ensure superior performance.

Q2: What is the operating temperature range for the rubber foam insulation?

A2: The insulation tubes are designed to withstand a wide temperature range, performing exceptionally well from -50°C to 110°C, verified by standard testing.

Q3: How does this product perform in fire situations?

A3: It offers excellent fire safety performance, achieving Class 0 & Class 1 fire ratings according to BS 476 Part 6 & Part 7 standards. It also features a high oxygen index (≥36) and low smoke density.

Q4: Is the rubber foam insulation moisture resistant?

A4: Yes, the material features good moisture resistance and has a very low water vapor permeability (≤0.91×10 ﹣¹³ Kg/(m.s.pa)), which helps prevent condensation and water absorption.

Q5: Does this material provide thermal and sound insulation?

A5: Absolutely. It has low thermal conductivity (with a K-Value of ≤0.030 W/(m.k) at -20°C) and excellent sound absorption properties, making it highly energy-efficient and effective for acoustic control.

Q6: How durable is the insulation tube against external environments?

A6: The material shows good resistance to fungi (ASTM 21), ozone (GB/T 7762-1987), and UV/weather conditions (ASTM G23), ensuring a long-lasting and stable service life.
