| Technical Data | |||
|---|---|---|---|
| Property | Unit | Value | Test Method |
| Temperature range | °C | (-50 - 110) | GB/T 17794-1999 |
| Density range | Kg/m3 | 45-65Kg/m3 | ASTM D1667 |
| Water vapor permeability | Kg/(m.s.pa) | ≤0.91×10 ﹣¹³ | DIN 52 615 / BS 4370 Part 2 1973 |
| μ | - | ≥10000 | - |
| Thermal Conductivity | W/(m.k) | ≤0.030 (-20°C) | ASTM C 518 |
| ≤0.032 (0°C) | |||
| ≤0.036 (40°C) | |||
| Fire Rating | - | Class 0 & Class 1 | BS 476 Part 6 part 7 |
| Flame Spread and Smoke Developed Index | - | 25/50 | ASTM E 84 |
| Oxygen Index | - | ≥36 | GB/T 2406, ISO4589 |
| Water Absorption, %by Volume | % | 20% | ASTM C 209 |
| Dimension Stability | - | ≤5 | ASTM C534 |
| Fungi resistance | - | Good | ASTM 21 |
| Ozone resistance | - | Good | GB/T 7762-1987 |
| Resistance to U.V. and weather | - | Good | ASTM G23 |
The high density and closed structure of selected raw material has the ability of low thermal conductivity and stable temperature and has an isolation effect of hot and cold medium.
When burned by fire, the insulation material do not melt and resulting in low smoke and do not make the flame spread which can guarantee the using safety; the material is determined as nonflammable material and the range of Using temperature is from -50℃ to 110℃.
The environmental friendly raw material has no stimulation and pollution, no hazard to health and environment. Moreover, it can avoid the mold growth and mouse biting; The material has the effection of corrosion-resistant, acid and alkali, it can increase the life of using.
It is convenient to install due to it is not need to install other auxiliary layer and it is just cutting and conglutinating. It will save the manual work greatly.
The operating temperature range for this insulation material is from -50°C to 110°C, making it suitable for both cold and hot media applications.
Yes, it features a Class 0 & Class 1 fire rating according to BS 476 Part 6 & 7 standards. It is determined as nonflammable, does not melt, produces low smoke, and prevents flame spread.
With a low water vapor permeability of ≤0.91×10 ﹣¹³ Kg/(m.s.pa) and a closed structure, the material effectively resists moisture penetration and maintains a stable thermal resistance.
Absolutely. The raw material is eco-friendly, causing no stimulation or pollution. It is hazardous-free, resists fungi and mold growth, and provides resistance to corrosion, acids, and alkalis.
Installation is highly convenient and requires no additional auxiliary layers. It can be easily cut to size and conglutinated, which significantly reduces labor time and costs.
Yes, the material exhibits good resistance to ozone, UV radiation, and weathering, ensuring a long service life even when exposed to outdoor environments.
